The flatbed cutting plotter Secabo FC50 including software is ideally suited for the production of small series and design samples. The compact desktop device offers a maximum working area of 35cm x 52cm and reliably fixes the applied material on a vacuum table. The underlying felt mat allows smooth work even with complete material averages. As an alternative to the drag knife, there are two groove and groove tools in different sizes. Thus, depending on the paper thickness, the right tool is available to cut out objects with exact contour and to create grooves or folded edges. The multilingual cutting software DrawCut PRO and the multi-registration mark recognition system LAPOS Q are included in delivery and support professional results. The vacuum pump with acoustic enclosure is already included in delivery, the silencer for noise reduction is optionally available.
|countour cutting function||LAPOS Q, sequential cut marks|
|scope of delivery||Flatbed cutting plotter, multilingual cutting software DrawCut PRO (Windows), drag knife, ball-bearing knife holder, plotter, grooving tool in two sizes, connection cable, vacuum pump, felt mat for vacuum table, acoustic enclosure and German user manual.|
|max. work area||35cm x 52cm|
|max. thickness||1,5 mm|
|downforce||50g - 500g g|
|control||back-illuminated graphic LCD display with gel buttons|
|Max. cutting speed||600 mm/s|
|Dimensions (W x D x H)||76cm x 86cm x 30cm|
|max. grammage||400 g / m²|
|weight without packaging||35,00 kg|
|weight with package||72,00 kg|
Drag knife for the flatbed cutting plotter of the Secabo FC series, cutting angle 45°, wedge...
Drag knife for the flatbed cutting plotter of the Secabo FC series, cutting angle 60°, wedge...
Grooving tool for the flatbed cutting plotter of the Secabo FC series, groove diameter 2mm and...
